Carbon / Stainless Steel PSA Nitrogen Generator 3 - 1000Nm3/H Psa N2 Generator

China Manufacture of PSA Nitrogen Generator 3-1000Nm3/h wiht lower Price high quality

PSA Nitrogen Generator

Technical indexes:

1) Nitrogen runoff: 3 - 2000Nm3/h

2) Nitrogen purity: 98 - 99.999%

3) Nitrogen pressure: 0.1 – 0.7Mpa

4) Dew point: -45°C

5) Purification not needed, as nitrogen of 99.999% purity is produced

COMPANY BUSINESS:

On-site Nitrogen plant

PSA Nitrogen generator

General purpose nitrogen generators

High purity nitrogen generators

Membrane N2generators

Nitrogen Purification Equipment

PSA O2 generators

Industrial oxygen generators

Medical oxygen generators

Membrane O2 generators

Spare parts&Cosumables of N2/ O2 generators

Equipment selection and matching, technician training, installation and commissioning.

Principles of PSA nitrogen generator

PSA nitrogen technology utilizes two towers which are filled with carbon molecular sieve (CMS). Compressed air enters the bottom of one tower. While the smaller oxygen molecules are adsorbed by the CMS, the larger nitrogen molecules pass through the sieve and are stored. Once the CMS of the working tower is saturated with oxygen, the regeneration of the CMS in the tower starts to work by depressurizing, and while another tower is switched to start the process over again.

Advantages:

1. More reliable:
* Tiancheng standardized air separation systems based on proven state of the art technologies in history of many years application in fields.
* Simplified engineering design idea with much less moving parts, guarantees maximum reliability and minimal maintenance

2. More economical:
* More advanced and more economical air separation modules.
* PLCcomposition control system reduces air consumption capacity, saves energy cost.

3. More convenient:
* Control system enables parameters of capacity, purity, and pressure of product gases online display on panel screen, gives running problem alarm, and reminds of maintenance.
* Skid mounted design, easy installation.

The main technical parameter list:

specifications	Nitrogen production Nm3/h	power (kW)	purity (%)	Air pressure Mpa	Producing nitrogen pressure Mpa	Overall dimensions mm
TY-3	3	0.5	99.5-99.99	0.8-1.0	0.1-0.65	570570950
TY-3	Note: for a pillow packaging machine inflatable, form a complete set of the displacement of air machine:≥0.4m³/min,≤The oil content:3ppm
TY-5	5	0.5	99.5-99.99	0.8-1.0	0.1-0.65	5705701200
TY-5	Note:for two inflatable pillow packaging machine,form a complete set of air compressor exhaust:≥0.6m³/min,≤The oil content:3ppm
TY-10	10	1	99.5-99.99	0.8-1.0	0.1-0.65	135012001650
TY-10	Note:for four pillow packaging machine or two vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥0.9m³/min,≤The oil content:3ppm
TY-15	15	1	99.5-99.99	0.8-1.0	0.1-0.65	135012001650
TY-15	Note:for five pillow packaging machine or three vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥1.25m³/min,≤The oil content:3ppm
TY-20	20	2	99.5-99.99	0.8-1.0	0.1-0.65	140012001800
TY-20	Note:for seven pillow packaging machine or five vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥1.5m³/min,≤The oil content:3ppm
TY-30	30	2	99.5-99.99	0.8-1.0	0.1-0.65	140012001800
TY-30	Note:for ten pillow packaging machine or seven vertical packaging machine inflatable,form a complete set of air compressor exhaust:≥2m³/min, ≤The oil content:3ppm
TY-40 TY-50 TY-60 TY-70 TY-80 TY-100 TY-200
